NVUM4-SP Novusun

  • Support 4-axis CNC control.

  • Power of the control board: voltage 12-24 V DC, current more than 500 mA.

  • The maximum frequency of the output pulse is 100 kHz, and the pulse width can automatically change depending on the frequency of the pulse.

  • Support for the operating system Windows XP, Windows 7 (32 / 64bit), Windows 8, Windows 10.

  • Applicable to all versions of DrufelCNC software.

NVUM4-SP Novusun

Download user manual for cnc usb motion controller NVUM4SP. If you want us to support your controller, let us know! Fill out the feedback form.
